TankOne 4.5 Gallon Thermal Expansion Tank

Introducing the Koflex 4.5 gallon thermal expansion tank – the safe solution to compensating for thermal expansion in water heaters. As water heats up, it expands and can cause excessive pressure and damage to the plumbing system. The Koflex tank is made of 16-gauge steel and butyl rubber diaphragm, ensuring durability and reliability. The tank is pre-charged at 40 psi for convenience and comes with a 5-year warranty.

-Stainless Steel 3/4″ MIP w/Hex
-NSF 61 Compliant
-Protects Water Heater, Fixtures and Appliances
-Prevents Dangerous Pressure Build Up
-Provides a Reservoir for Expanded Water Volume
-Stainless Steel 3/4″ MIP w/Hex
-NSF 61 Compliant
-Protects Water Heater, Fixtures and Appliances
-Prevents Dangerous Pressure Build Up
-Provides a Reservoir for Expanded Water Volume

Back to List

Models

  • Part #

    Description

    Qty/Box

    KF-TET-4

    4.5 Gallon Thermal Expansion Tank

    1

Technical Data

CERTIFICATIONS, APPROVALS, LISTINGS, & COMPLIANCE

  • cUPC Certified
  • NSF 61 Compliant

Materials

Shell16 gauge cold rolled steel
Diaphragm100% butyl rubber lined with polypropylene
ConnectionStainless steel 3/4″ MIP
FinishHigh quality coating prevents corrosion
Air Charging PortBrass port with O-ring seal

Specifications

Connection Size3/4″ MIP
Tank Volume4.5 Gallons
Factor Pre-Charge40 psi
Maximum Pressure150 psi
Maximum Temperature200°F
